ATHENA S3
HORIZONTAL FLOW WRAPPER
-
Made in the USA
-
Complete 304 stainless steel construction
-
5.5ft Lugged Infeed
-
144 mm jaw Centrex - max product height of up to 4.5”
-
Pair of jaws with cross serration parallel to the knife
-
18” Film Reel Mount
-
Fin seal-propelling rollers 1st pair cold, 2nd pair hot
-
Easy thread film wrap design
-
Dual Temperature Controlled Jaws (Built in HMI)
-
(NPNB) No Product No Bag
-
(SAT) Self Adjusting Temperature
-
(dynamic temperature control, automatically adjusts with speed)
-
(APC) Athena Power Conserve
-
Up to 99 product presets
-
Recipe management incl. temperature
-
EWON cozy, remote troubleshooting access with secure VPN tunnel
-
Omron PLC, coordinated servo motion control
-
3 axis coordinated motion servo system
-
7” Omron HMI touch screen
-
Up to 300 packs per minute (speed based on product dimensions)


OPTIONS
-
Print Registration system
-
Machine Vision (Quality Control)
-
Collaborative Robot (Pick and place, gluing, conveyor tracking & much more)
-
ID Bar Code Reader & Tracker (Inventory management)
-
Date Coder, Thermal Jet Printer
-
Heavy Duty Casters
-
Extended Infeed
-
Airplane, Round Hole Punch or Tear Notch
USED FOR
-
Single piece items
-
Multi-packs
-
Bakery Goods
-
Confectionary
-
Pharmaceutical and healthcare
-
Hardware and toiletries
-
Food (cold or hot)
PACKAGING MATERIALS
-
BOPP
-
PE
-
Printed Films
-
Most Heat Sealable Films
